P1.25 P1.538 P1.667 P1.86 P2 INDOOR FINE-PITCH LED DISPLAY 640*640MM

•
  •
  •
  •



• Indoor P1.25 P1.538 P1.667 P1.86 P2 SMD Main specification
  Indoor P1.25 P1.538 P1.667 P1.86 P2	Item	Parameter
  	Model Number	P1.25-64S P1.53-52S P1.667-48S P1.86-43S P2-40S
  	Module size	320mm(H)*160mm(V)
  	Pixel pitch	1.25mm 1.538mm 1.667mm 1.86mm 2mm
  	Pixels Density	640000 dots/m² 422500 dots/m² 360000 dots/m² 288900 dots/m² 250000 dots/m²
  	Pixel configuration	1R1G1B
  	Package mode	SMD1010 SMD1212 SMS1212 SMD1515 SMD1515
  	Drive type	Constant drive (IC2153)
  	Scan mode	1/64scan 1/52scan 1/48scan 1/43scan 1/40scan 1/40scan
  	Port type	HUB320
  	Brightness of white balance	≥1000cd/m²
  	Best viewing distance	2M～30M
  	Best viewing distance	160°(W) 120°(H)
  	Temperature	storage:-35℃～+85℃    working:-20℃～+50℃
  	Refresh	>3840HZ
  	Gray Grade	14 bits
  	Thickness	85mm
  	Working voltage	AC220V±10%
  	Average Power consumption	450W/S
  	Cabinet size	640*640mm
  	Pixel resolution	256dots(W)*128dots(H) 208dots(W)*104dots(H) 192dots(W)*96dots(H) 172dots(W)*86dots(H) 160dots(W)*80dots(H)
  	Material	Die cast aluminum
  	Average Power consumption	400W/S
  		If >6000 cd/㎡; 900W/S
  	System support	Linsn / Nova star
