INDOOR P2.5 P3.076 P4 P5 P10 LED DISPLAY 640*640MM

•
  •
  •
  •



• Indoor P2.5 P3.076 P4 P5 P10 SMD Main Specification
  Indoor P2.5 P3.076 P4 P5 P10	Item	Parameter
  	Model Number	P2.5-32S P3.076-26S P4-16S/20S P5-16S P10-8S
  	Module size	320mm(H)*160mm(W) 320mm(H)*160mm(W) 256mm(H)*128mm(W)/320mm(H)*160mm(W) 320mm(H)*160mm(W) 320mm(H)*160mm(W)
  	Pixel pitch	2.5mm 3.076mm 4mm 5mm 10mm
  	Pixels Density	160000 dots/m² 105625 dots/m² 62500 dots/m² 40000 dots/m²
  	Pixel configuration	1R1G1B
  	Package mode	SMD2121
  	Drive type	Constant drive (IC:2037/2153)
  	Scan mode	1/32scan 1/26scan 1/16scan/1/20scan 1/16scan 1/8scan
  	Port type	HUB75
  	Brightness of white balance	≥2000cd/m²
  	Best viewing distance	2M～50M
  	Best viewing distance	160°(W) 120°(H)
  	Temperature	storage:-35℃～+85℃    working:-20℃～+50℃
  	Refresh	>1920Hz
  	Gray Grade	14 bits
  	Thickness	85mm
  	Working voltage	AC220V±10%
  	Average Power consumption	450W/S
  	Cabinet size	640*640mm
  	Material	Die cast aluminum
  	Average Power consumption	400W/S
  		If >6000 cd/㎡; 800W/S
  	System support	Linsn / Nova star
