P5 P8 P10 OUTDOOR FOOTBALL LED DISPLAY 960*960MM

Outdoor P5 P8 P10 SMD Main specification
Outdoor P5 P8 P10	Item	Parameter
	Model Number	P5-8S P8-4S/5S P10-4S
	Module size	320mm(H)*160mm(V)
	Pixel pitch	5mm 8mm 10mm
	Pixels Density	40000dots/m² 15625dots/m² 10000dots/m²
	Pixel configuration	1R1G1B
	Package mode	SMD1921 SMD3535 SMD3535
	Drive type	Constant drive (IC:2037/2153)
	Scan mode	1/8scan 1/4 1/5scan 1/4scan
	Port type	HUB75
	Brightness of white balance	≥65000cd/m²
	Best viewing distance	4M-30M 6M-30M 8M-30M
	Best viewing distance	160°(W) 120°(H)
	Temperature	storage:-35℃～+85℃ working:-20℃～+50℃
	Refresh	>1920-3840HZ
	Gray Grade	14 bits
	Thickness	85mm
	Working voltage	AC220V±10%
	Average Power consumption	450W/S
	Cabinet size	960*960mm
	Material	Die cast aluminum
	Average Power consumption	400W/S
	Average Power consumption	If >6000 cd/㎡; 800W/S
	System support	Linsn / Nova star
