P1.25 P1.538 P1.667 P1.86 P2 P2.5 INDOOR FINE-PITCH LED DISPLAY 640*480MM

•
  •
  •
  •



• •


    Indoor P1.25 P1.538 P1.667 P1.86 P2 SMD Main specification
    Indoor P1.25 P1.538 P1.667 P1.86 P2	Item	Parameter
    	Model Number	P1.25-64S P1.53-52S P1.667-48S P1.86-43S P2-40S P2.5-32S
    	Module size	320mm(H)*160mm(V)
    	Pixel pitch	1.25mm 1.538mm 1.667mm 1.86mm 2mm 2.5mm
    	Pixels Density	640000 dots/m² 422500 dots/m² 360000 dots/m² 288900 dots/m² 250000 dots/m² 160000 dots/m²
    	Pixel configuration	1R1G1B
    	Package mode	SMD1010 SMD1212 SMS1212 SMD1515 SMD1515 SMD2121
    	Drive type	Constant drive (IC2153)
    	Scan mode	1/64scan 1/52scan 1/48scan 1/43scan 1/40scan 1/40scan 1/32scan
    	Port type	HUB320
    	Brightness of white balance	≥1000cd/m²
    	Best viewing distance	2M～30M
    	Best viewing distance	160°(W) 120°(H)
    	Temperature	storage:-35℃～+85℃    working:-20℃～+50℃
    	Refresh	>3840HZ
    	Gray Grade	14 bits
    	Thickness	85mm
    	Working voltage	AC220V±10%
    	Average Power consumption	450W/S
    	Cabinet size	640*480mm
    	Pixel resolution	256dots(W)*128dots(H) 208dots(W)*104dots(H) 192dots(W)*96dots(H) 172dots(W)*86dots(H) 160dots(W)*80dots(H) 128dots(W)*64dots(H)
    	Material	Die cast aluminum
    	Average Power consumption	400W/S
    		If >6000 cd/㎡; 900W/S
    	System support	Linsn / Nova star
